Adding a Box

The Box object is a commonly used tool in 3D modeling, and can be used to create many everyday objects. For example, it can be used to model the legs of outdoor tables and benches, as well as the rafters of a pergola.

To add a box:

1. From the Modeling tab, click Add Box.
2. Click to place one corner of the box. Press the Esc key to cancel.
3. Click to place the opposite corner of the box. If you would like to input the distance and angle manually, place the first corner and then click Enter.
